CW TruSpace Directional Ortho Tools

AUTOCAD PRO REVIT ULTIMATE

The directional Ortho View tools enable users to easily navigate to ortho views, providing simple navigation and orientation support.

Mouse Control:  Click the Ortho Views button image-20240703-091418.png to expand the menu. Select the orientation for the view.

Top View: Shift + T

Down View: Shift + D

Left View: Shift + L



  Right View: Shift + R

Front View: Shift + F

Back View: Shift + B
