North Arrow

Prev Next

Function

Inserts a north arrow into your diagram that can be placed and sized as needed.

Procedure

Select the North Arrow button from the Labeling ribbon.

Left click to insert the North Arrow.

With the north arrow selected, use the grips to adjust the size and rotation.

The style can be adjusted from the Properties panel, along with color, transparency, and size.
